Self SLT30-24VFG (24 V - 30 W), Power supply

Self SLT30-24VFG (24 V - 30 W), Power supply

Self SLT30-24VFG (24 V - 30 W), Power supply
Self SLT30-24VFG (24 V - 30 W), Power supply

Self SLT30-24VFG (24 V - 30 W), Power supply

€25.18
Low Stock, only 10 pcs.
SKU
32142

This type of power supply is an exclusively designed stabilized power supply for LED lamp. With constant voltage (CV) technology, it is suitable for constant voltage lamps (12/24VDC) connected in parallels. As an advantage of constant voltage (CV) technology, a switch can be installed between secondary side and lamps. The built-in protection circuit will shut down the power supply in case of such faults as: open circuit, short circuit, over load or over temperature. The power supply will restart automatically after fault correction.

Features

  • Input voltage: 220-240 VAC
  • Input frequency: 50/60 Hz
  • Input current: 0.16 A
  • Constant output voltage: 24 VDC
  • Output current: 0-1.25A
  • Rated power: 0-30 W
  • Independent power supply for constant voltage LED lamp
  • Class II protection against electric shock from direct and indirect contact
  • Super thin
  • SELV outputn
  • Open circuit,short circuit,over load and over temperature protection
  • Auto restart after fault conditions removal
  • No load power consumption =0.3W
  • Efficiency:84% (AC230V,full load)
Technical Data
SKU 32142
Weight brut (g) 135.000000
Brand SELF Electronics Co.,Ltd.
Manufacturer Product Code SLT30-24VFG
Transformer Output Voltage 24V
Power (W) 30
IP Protection IP20
Dimmable Not Dimmable
Dimensions: Length (cm) 24.6
Dimensions: Width (mm) 30
Dimensions: Height (mm) 16
Availability beyond shown stock: YES
