Constant Voltage Power Supply Mean Well LPF-90D-24 IP67 230V to 24V 3.75A 90W DIM

Constant Voltage Power Supply Mean Well LPF-90D-24 IP67 230V to 24V 3.75A 90W DIM

Constant Voltage Power Supply Mean Well LPF-90D-24 IP67 230V to 24V 3.75A 90W DIM
Constant Voltage Power Supply Mean Well LPF-90D-24 IP67 230V to 24V 3.75A 90W DIM

Constant Voltage Power Supply Mean Well LPF-90D-24 IP67 230V to 24V 3.75A 90W DIM

€47.87
Stock >10 pcs
SKU
95174

Constant Voltage Power Supply Mean Well LPF-90D-24 IP67 230V to 24V 3.75A 90W DIM

Mean Well constant voltage LED transformer for use with LED modules and strips that require 24VDC voltage. The components can be connected in parallel so the total power of the chain is max 3750mA or 90 W. Compact size, dimensions(mm): 161*61*36mm .

Features:
  • Built-in 3 in 1 dimming function (1~10VDC, PWM signal or resistance)
  • Fully encapsulated with IP67 level
  • Protections: Short circuit/ Overload/ Over voltage/ Over temperature
  • 90~305VAC input, built-in active PFC function (200~400VAC for LPFH-60/60D)
  • Built-in active PFC function
  • Fully isolated plastic case
  • Isolation class II, no F.G.
  • Class 2 power unit
  • Suitable for dry, damp, wet location
  • 5 years warranty
Technical Data
SKU 95174
Weight brut (g) 700.000000
Manufacturer Mean Well
Manufacturer Product Code LPF-90D-24
Output Current (Range) 3750
Transformer Output Voltage 24V
Power (W) 90
IP Protection IP67
Dimmable Dimmable
Dimensions 161x61x36mm
Dimensions: Length (cm) 16.1
Dimensions: Width (mm) 61
Dimensions: Height (mm) 36
Product Family LPF
Availability beyond shown stock: YES
