Constant Voltage Power Supply Mean Well NPF-120D-24 IP67 230V to 24V 5A 120W

Constant Voltage Power Supply Mean Well NPF-120D-24 IP67 230V to 24V 5A 120W

Constant Voltage Power Supply Mean Well NPF-120D-24 IP67 230V to 24V 5A 120W
Constant Voltage Power Supply Mean Well NPF-120D-24 IP67 230V to 24V 5A 120W Constant Voltage Power Supply Mean Well NPF-120D-24 IP67 230V to 24V 5A 120W

Constant Voltage Power Supply Mean Well NPF-120D-24 IP67 230V to 24V 5A 120W

€57.17
Low Stock, only 7 pcs.
SKU
95315

Constant Voltage Power Supply Mean Well NPF-120D-24 IP67 230V to 24V 5A 120W

Mean Well constant voltage LED transformer for use with LED modules and strips that require 24VDC voltage. The components can be connected in parallel so the total power of the chain is max 5000mA or 120 W. Compact size, dimensions(mm): 191*63*37.5mm.

Features:
  • Fully encapsulated with IP67 level
  • Protections: Short circuit/ Over Current/ Over voltage/ Over temperature
  • Built-in 3 in 1 dimming function (0~10VDC, PWM signal or resistance, dim-to-off )
  • 90~305VAC input, built-in active PFC function
  • High efficiency up to 90.5%
  • Cooling by free air convection
  • Built-in active PFC function
  • Fully isolated plastic case
  • Class II power unit, no FG
  • Suitable for dry, damp, wet location
  • No load power consumption <0.15W
  • 5 years warranty
Technical Data
SKU 95315
Weight brut (g) 970.000000
Manufacturer Mean Well
Manufacturer Product Code NPF-120D-24
Output Current (Range) 5000
Transformer Output Voltage 24V
Power (W) 120
IP Protection IP67
Dimmable Dimmable
Dimensions 191x63x37.5mm
Dimensions: Length (cm) 19.1
Dimensions: Width (mm) 63
Dimensions: Height (mm) 67.5
Product Family NPF
Availability beyond shown stock: YES
