FlexMatrix-576-5080 LED Module 576 LEDs 5700K 24V 7200lm 39.74W 18x18cm (220000 lm/sqm)
- High-density flexible LED matrix delivering very high luminous flux from a compact surface
- 36 individually separable 16-LED segments
- 120° beam angle
- Approximately 220,000 lm/m² luminous-flux density
- Approximately 181 lm/W luminous efficacy
- 3-Step MacAdam colour consistency
- Developed and manufactured in Germany
The FlexMatrix-576-5080 is a high-density flexible LED matrix for applications that need an intense, uniform field of white light from a very compact area. The 179 × 179 mm module contains 576 LEDs and produces 7200 lm at 5700 K while consuming only 39.74 W.
With an efficacy of approximately 181 lm/W and a luminous-flux density of about 220,000 lm/m² of module area, the FlexMatrix delivers exceptionally high output from a flexible light engine only 1.1 mm high.
Features of the FlexMatrix-576-5080 LED module
- 576 LEDs on a flexible 179 × 179 mm matrix
- 5700 K cold / daylight white light
- CRI 80+
- 7200 lm luminous flux
- Approximately 220,000 lm/m² luminous-flux density
- 39.74 W power consumption
- Approximately 181 lm/W luminous efficacy
- 24 V DC constant-voltage operation
- Reference current approximately 1656 mA
- PWM dimmable with a compatible controller
- 120° beam angle
- 3-Step MacAdam colour consistency
- 36 individually separable 16-LED segments
- Each 16-LED segment can be divided again for finer geometry adjustment
- Only 1.1 mm high
- Heat-conducting adhesive foil on the rear
- Rated lifetime greater than 60,000 h L80B10C1
- EN 62471 photobiological safety classification: RG0
- Made in Germany
Flexible high-density area lighting
FlexMatrix combines the output density of a compact LED panel with the mechanical flexibility of a thin carrier. This is useful when a powerful area source must conform to a slightly curved surface or fit into a housing where a conventional rigid panel would be difficult to integrate.
The segmentation concept makes the matrix much more adaptable than a fixed rectangular PCB. The complete 18 × 18 cm light engine can be divided into smaller sections and rearranged for unusual optical geometries, prototypes and specialized luminaires.
Machine vision, image capture and inspection lighting
The very high LED density and 5700 K daylight-white output make FlexMatrix particularly suitable for machine vision, image capturing, quality control and industrial inspection. A dense source can be used close to a diffuser or integrating element to create a bright, even field for cameras and optical sensors.
The module is also relevant to flat-field illumination and diagnostic imaging setups where a compact area source is preferred over a long linear fixture.
Compact high-output backlighting and signage
FlexMatrix is also suited to high-output backlighting, signage and billboard or display systems where a very high amount of light must be generated from a small footprint.
Because the output density is much higher than conventional backlighting boards, diffuser distance, thermal design and required surface luminance should be evaluated carefully to avoid unnecessary brightness and heat.
Ceiling lights and custom area luminaires
The module can be used in compact ceiling luminaires and other custom area lights where a high-output source must fit into limited space. The flexible carrier and separable segments give designers more freedom than a conventional rigid light panel.
Thermal and electrical integration
Operate FlexMatrix from a regulated 24 V DC constant-voltage power supply. At nearly 40 W in a 179 × 179 mm area, the module should be mounted to a suitable thermally conductive surface using the rear heat-conducting adhesive foil.
For segmented or rearranged installations, conductor sizing and power distribution should be designed for the actual connected geometry. PWM dimming can be used when adjustable output is required.
Developed and manufactured in Germany
We develop and manufacture professional LED strips and modules in Germany, combining more than 20 years of LED application experience with automated production and application engineering. Our capabilities include Reel-to-Reel manufacturing for flexible substrates as well as controlled SMT assembly for rigid and flexible LED modules.
For project customers, we can also support custom dimensions, LED selection, thermal design, optical layout, prototyping and series production. This allows the light engine to be adapted to the illuminated surface instead of forcing the project around a standard LED-strip geometry.
Learn more about Lumistrips and our LED manufacturing capabilities.
| SKU | 45239 |
|---|---|
| Weight brut (g) | 15.000000 |
| Color | Cold White |
| Color Temperature | 5700K |
| Color Rendering Index | 80 |
| Bright like (W) | 480 |
| Luminous Flux Typ (lm) | 7200 |
| Efficacy (lm per W) | 181 |
| Power (W) | 39.74 |
| Dimmable | Dimmable |
| Viewing Angle | 120° |
| Lifetime for residential, 3h daily (yrs) | 55 |
| Product lifetime (h) | 60000 |
| Lifetime for commercial, 12h daily (yrs) | 14 |
| Manufacturer Product Code | 45239 |
| Product Family | FlexMatrix5080 |
| Strip Type | Flexible |
| LEDs number per sales unit | 576 |
| Dimensions | 179 x 179 x 1.1 mm |
| Dimensions: Length (cm) | 179 |
| Dimensions: Width (mm) | 179 |
| Dimensions: Height (mm) | 1.10 |
| Brand | Lumistrips |
| Forward Voltage Typ (V) | 24 |
