SmartArray Q1 LED Module square 13.5mm warm white 2700K 24V 520lm 4.8W
- Compact Nichia LED module designed as a flexible alternative to conventional COB light sources
- Approximately 520 lm luminous flux
- 3-Step MacAdam colour consistency
- 24 V DC constant-voltage operation
- Compact dimensions approximately 13.5 × 13 × 1.8 mm
- Single high-output Nichia LED
- Made in Germany with a 5-year commercial warranty
The SmartArray Q1 2700 K module is an earlier 24 V compact point-source design in the SmartArray family. A single Nichia LED on a 13.5 × 13 mm PCB delivers approximately 520 lm from 4.8 W, providing a simple constant-voltage alternative to conventional COB modules.
Features of the SmartArray Q1 2700 K module
- Single high-output Nichia LED
- 2700 K warm white light
- CRI 80+
- Approximately 520 lm luminous flux
- 24 V DC constant-voltage operation
- Power consumption approximately 4.8 W
- Compact dimensions approximately 13.5 × 13 × 1.8 mm
- 3-Step MacAdam colour consistency
- Compatible with compact mounting and optical accessories
- Suitable as a replacement for COB modules
- 5-year commercial warranty, subject to current warranty conditions
- Made in Germany
Compact light engine for bulbs, downlights, spotlights and floodlights
SmartArray modules are designed for compact luminaires where high output must come from a very small source area. They are particularly well suited to LED bulb manufacturing, downlights, spotlights and floodlights.
The compact PCB makes SmartArray a practical alternative to COB modules when the designer prefers discrete Nichia LEDs, a defined board geometry and more flexibility in the electrical architecture. The 24 V architecture simplifies power-supply selection for luminaire makers who prefer a constant-voltage system.
Accessory-friendly compact module
The original Q1 format was developed for easy integration with compact holders and secondary optics. Its small square PCB allows the light source to sit close to the optical centre of a reflector or lens system while keeping the electrical connection straightforward.
White-light quality for the application
The warm white tone is well suited to hospitality, residential lighting and luminaires designed for a softer, more relaxed atmosphere. CRI 80+ provides a practical balance of efficiency and colour rendering for general professional lighting.
For more background, see our colour temperature guide.
Designed and manufactured in Germany
We develop and manufacture professional LED modules in Germany, combining more than 20 years of LED application experience with controlled SMT production and application engineering. SmartArray modules are designed as compact light engines for luminaire manufacturers who need defined optical, electrical and thermal behaviour from a very small PCB.
For OEM and project customers, we can also support LED selection, PCB adaptation, optics integration, thermal design, prototyping and series production. This allows the module to be matched to the fixture and optical system instead of forcing the luminaire around a generic COB or anonymous LED board.
Learn more about Lumistrips and our LED manufacturing capabilities.
| SKU | 32019 |
|---|---|
| Weight brut (g) | 1.000000 |
| Color | Warm White |
| Color Temperature | 2700K |
| Color Rendering Index | 80 |
| Luminous Flux Typ (lm) | 520 |
| Efficacy (lm per W) | 109 |
| Energy Class 2022 | E |
| Warranty (months) | 60 |
| Lifetime for residential, 3h daily (yrs) | 55 |
| Product lifetime (h) | 60000 |
| Lifetime for commercial, 12h daily (yrs) | 14 |
| Manufacturer Product Code | 32019 |
| Product Family | Smart Array LED strip |
| Strip Type | Rigid |
| Dimensions | 13.5x13x1.8 |
| Dimensions: Length (cm) | 1.35 |
| Dimensions: Width (mm) | 13 |
| Dimensions: Height (mm) | 1.8 |
| Brand | Lumistrips |
| Manufacturer Part Number | 4260127457286 |
| Forward Voltage Typ (V) | 24 |
| Availability beyond shown stock: | YES |
