FlexOne4080 Samsung LED Strip cold white 6500K 19000lm 12V 100 LEDs/m 5m reel (3800lm/m 42W/m)
- High-output flexible LED strip with unusually fine single-LED segmentation
- Can be cut after every LED at 10 mm intervals
- 19,000 lm per 5 m reel / 3800 lm per metre
- 100 Samsung LM283 LEDs per metre / 500 LEDs per reel
- 12 V DC operation
- Dimmable with a compatible 12 V system
- Made in Germany with a 5-year commercial warranty
The FlexOne4080 is an ultra-high-output professional flexible LED strip for demanding linear-lighting applications. With 100 Samsung LM283 LEDs per metre and 3800 lm/m, it delivers the output of a powerful linear light engine while still retaining the segmentation and installation freedom of a flexible PCB.
This 6500 K version produces 19,000 lm from the 5 m reel at 42 W/m. The 19.5 mm wide strip can be cut after every LED at 10 mm intervals, making it unusually adaptable for high-output luminaires, bright coves and commercial lighting assemblies.
Features of the FlexOne4080 LED strip
- 6500 K white light
- CRI 80+
- 19,000 lm per 5 m reel / 3800 lm per metre
- 42 W per metre
- 100 Samsung LM283 LEDs per metre / 500 LEDs per reel
- 12 V DC operation
- Can be cut after every LED at 10 mm intervals
- 19.5 mm wide flexible PCB
- Integrated linear control for consistent brightness along the strip
- Dimmable with a compatible 12 V system
- Thermally conductive double-sided adhesive backing
- Uniform white light through controlled LED binning
- 5-year commercial warranty, subject to current warranty conditions
- Made in Germany
Ultra-high-output linear luminaires
At 3800 lm/m, the FlexOne4080 is designed for linear luminaires where the LED engine must provide substantial general or task illumination from a compact source. Its 10 mm segmentation allows the active light length to be matched closely to the fixture dimensions.
This is especially useful for commercial luminaires, continuous light lines, work-area lighting and custom fixtures where rigid LED boards would make length adjustment more difficult. See our linear fixture design guide for additional integration guidance.
Very bright cove and indirect lighting
The FlexOne4080 can be used for cove lighting when the reflected surface is intended to provide strong general illumination. Its output is substantially above typical decorative LED tape, making the cove itself part of the room's functional lighting system.
The 6500 K cold-white version creates a distinctly daylight-like appearance for laboratories, technical workplaces, industrial environments and other task-oriented spaces where a cool visual character is preferred.
Troffers and diffuse high-output luminaires
The strip is also suitable for troffers and diffuse commercial luminaires. Multiple strips can be arranged behind a diffuser to create a broad luminous surface, with the spacing determined by diffuser transmission, optical distance and the required uniformity.
White-light quality and colour temperature
Colour temperature strongly influences how a space is perceived: warmer white supports a more relaxed atmosphere, while neutral and cooler white light is often preferred in task-oriented and technical environments. For further guidance, see our colour temperature guide and CRI guide.
Installation and electrical integration
Operate the FlexOne4080 from a regulated 12 V DC constant-voltage power supply. The strip can be cut every 10 mm, allowing precise adjustment to custom luminaire lengths.
At 42 W/m, the electrical installation must be designed carefully. Use conductor sizes, feed-point spacing and power-supply capacity appropriate for the connected length so voltage drop remains controlled. Mount the strip on a stable surface using the thermally conductive adhesive backing.
Our manufacturing and quality promise
We develop and manufacture professional LED strips and modules in Germany, combining more than 20 years of LED application experience with automated production and application engineering. Our focus is on repeatable performance, carefully selected components and light engines that can be integrated reliably into professional lighting systems.
For project customers, we can also support custom development, PCB adaptation, LED selection, thermal design, prototyping and series production. This allows the light engine to be matched to the luminaire or architectural application instead of forcing the project around a generic LED tape.
Learn more about Lumistrips and our LED manufacturing capabilities.
| SKU | 31655 |
|---|---|
| Weight brut (g) | 1.000000 |
| Color | Cold White |
| Color Temperature | 6500K |
| Color Rendering Index | 80 |
| Luminous Flux per meter | 3800 |
| Bright like (W) | 317 |
| Luminous Flux Typ (lm) | 19000 |
| Efficacy (lm per W) | 91 |
| Energy Class 2022 | F |
| Power (W) | 210 |
| Viewing Angle | 120° |
| Warranty (months) | 60 |
| Lifetime for residential, 3h daily (yrs) | 55 |
| Product lifetime (h) | 60000 |
| Lifetime for commercial, 12h daily (yrs) | 14 |
| Manufacturer Product Code | 4260127451437 |
| Product Family | FlexOne4080 |
| Strip Type | Flexible |
| Strip LEDs per meter | 100 |
| LEDs number per sales unit | 500 |
| Dimensions | 5000x19.5x1.4 |
| Dimensions: Length (cm) | 500 |
| Dimensions: Width (mm) | 19.5 |
| Dimensions: Height (mm) | 1.4 |
| Brand | Lumistrips |
| Manufacturer Part Number | 4260127451437 |
| Forward Voltage Typ (V) | 12 |
| Availability beyond shown stock: | YES |
